CHASSIS 5-7
• Remove the rear lower fender fastener
6
.
• Remove the rear fender
7
.
FRONT GRIP
• Remove the front grip.
INSTALLATION
Install the exterior parts in the reverse order of removal. Pay
attention to the following points:
FOOTREST BAR
• Apply THREAD LOCK “1342” to the footrest mounting bolts
and tighten footrest mounting bolts the specified torque.
J99000-32050: THREAD LOCK “1342”
" Footrest mounting bolt: 55 N·m (5.5 kgf-m, 40.0 lb-ft)
