Suzuki LT-Z90K7 2007 User Manual

CHASSIS 5-47
REAR SUSPENSION
CONSTRUCTION
1
Rear shock absorber
9
Out spacer
2
Chain case cover
0
Swingarm pivot bush
3
Chain case
A
Swingarm
4
Chain guide
B
Spacer
"
5
Swingarm pivot shaft
A
Rear shock absorber upper bolt
ITEM N·m kgf-m lb-ft
6
Dust seal
B
Rear shock absorber lower bolt
A
29 2.9 21.0
7
Chain buffer
C
Swingarm pivot nut
B
94 9.4 18.0
8
Oil seal
C
102 10.2 74.0
