AMI Sample Sequencer
Product Description
A-96.250.661 / 120418 19
Step 3  The instrument has finished flushing the photometer with sample
stream 2.
– Sample stream 2 is selected and measured.
A
B
Photometer
6-way valve
C
D
Peristaltic pump
Flow cell block
1
123456
34
5
7
6
2
B
C
A
D
