6.3. Tube connections
The connection tubes between the flow cell block outlet and the
6-way valve inlet are not numbered. If you replace the tubes make
sure that the numbering of the flow cell block outlets corresponds to
the numbering of the 6-way valve inlets.
1
12345 6
3
4
5
7
6
2
A
B
