AMI Sample Sequencer
Installation
A-96.250.661 / 120418 37
3.5.2 Sample Sequencer Inputs
Signal inputs
from
AMI analyzer
The values of the AMI analyzer are transferred via signal output
1 and 2 to the AMI Sample Sequencers signal inputs 1 and 2. From
there the measuring values can be transferred and displayed at a
remote location.
Connect the signal inputs according to the table below.
Signal inputs
from External
Devices
Signal inputs
from PLC
device
Each sample stream is assigned to an input channel of the AMI
Sample Sequencer. The sample stream number corresponds with
the channel number.
If a PLC device is connected to the signal inputs 9 to 14 any sample
stream can be switched off or on by the PLC device.
3.5.3 Sample Sequencer Outputs
Current Out-
puts
The current outputs 17 to 22 can be used to display the measuring
values on a remote location.
The assignment of the terminals to the sample streams depends on
the selected parameter
Signal Inputs = 1
Signal Inputs = 2 (only up to 3 sample streams)
in the menu <Installation/Sequence/Signal Inputs>, of the AMI
Sample Sequencer.
NOTICE: Max. burden: 510 Ω.
If signals are sent to two different receivers, use signal isolator
(loop isolator).
Terminals Signal Use
34/32 Signal Input 1 Measuring value 1
31/32 Signal Input 2 Measuring value 2
Terminals Signal Use
23/25 Mark end of measurement Not applicable
27/29 System Alarm Flow alarm
