5.3. Software Structure
The menu structure depends on the settings of the AMI transmitter.
Therefore the following examples are only applicable with certain
configurations.
Menu 1 Messages
Reveals pending errors as well as an event history
(time and state of events that have occurred at an
earlier point of time).
It contains user relevant data.
Menu 2 Diagnostics
Provides user relevant instrument and sample data.
Menu 3 Maintenance
For instrument calibration, relay and signal output
simulation, and to set the instrument time.
It is used by the service personnel.
Menu 4 Operation
Not applicable.
Menu 5 Installation
For initial instrument set up by SWAN authorized
person, to set all instrument parameters. Can be
protected by means of password.
1
Messages
Maintenance
Diagnostics
Main Menu
Installation
1.1
Pending Errors
Messages
Message List
2.1
Signal Outputs
Identification
Sensors
Diagnostics
3.1
Signal Outputs
Maintenance
Set Time
01.01.05 16:30:00
Rotary Valve
5.1
Miscellaneous
Sequence
Sample Flow
Installation
To Next Page
