AMI Sample Sequencer
Program List and Explanations
A-96.250.661 / 120418 59
3 Maintenance
3.1 Signal Outputs
3.1.1 Signal Output 1 to 6:
Possibility to simulate a current output manually for test purposes.
To simulate a value proceed as follows:
1 Select one of the 6 signal outputs with the [ ] or [ ]
key.
2 Press [Enter].
3 Change the value with the [ ] or [ ] key.
Range: 0–20 mA
4 Press [Enter].
The value is simulated at the corresponding signal output.
3.2 Rotary Valve
Possibility to switch the 6-way valve manually to any channel for
test purposes.
To switch the 6-way-valve to a certain position proceed as follows:
1 Press [Enter].
2 Select the position you want to switch to with the [ ] or
[] key.
3 Press [Enter].
The 6-way-valve rotates to the defined position.
3.5 Set Time
Adjust date and time.
4 Operation
Not Applicable.
