AMI Sample Sequencer
Product Description
A-96.250.661 / 120418 21
Dimensions Dimensions: 280 x 850 x200 mm
Distance between mounting holes: 254 x 824 mm
Screws: 8 mm diam.
Panel material: Stainless steel
Weight: 8 kg
AMI
Sample Sequencer
Exit Enter
824 mm / 32
7
/
16
”
850 mm / 33½”
13 mm
254 mm / 10”
280 mm / 11”
13 mm
4x dia. 10 mm
