To print header again : press Print key longer than two seconds.
Following pages show printing examples in 80 column format. If tolerances mode is not activated, only the channel
number (with A+/-B mode or min/max indication) and measurement are printed. In tolerance mode, we have the
nominal value, upper and lower tolerances, dispersion i.e. difference between nominal value and measurement,
out of tolerance value (if there is one), External (E) or Internal (I) measurement indication, and finally if the
measurement is within tolerances (=), under (<) or over (>).
a/printing in normal measurement mode (not scanning) with header and tolerance mode not activated :
SYLVAC SA
Piece ident. : COUVERCLE
Drawing nbr : PM230.010.412
Work station : L 201
Date : 12/11/1998 Time : 14:37
CHANNEL MEAS. VALUE
1 8.383
1 8.354
1 8.382
1 8.381
1 8.375
1 8.371
b/ printing in scanning mode with header and tolerances enabled :
SYLVAC SA
Piece ident. : COUVERCLE
Drawing nbr : PM230.010.412
Work station : L 201
Date : 12/11/1998 Time : 14:37
CHANNEL MEAS.VALUE NOM.SIZE UPPER TOL LOWER TOL DEVIATION OUT OF TOL <=>
PIECE 1 : REJECT
1 8.379 8.350 0.020 -0.010 0.029 0.009 E >
2 5.092 5.100 0.000 -0.010 -0.008 E =
3 12.284 12.220 0.050 0.000 0.064 0.014 I >
4 7.004 7.000 0.050 -0.050 0.004 E =
