1.3.2 General method
All functions are directly accessible, e.g. by pressing the Tol key, tolerance indicators will be displayed. Pressing it
again causes the indicators to disappear. The numbers on the function keys are used to select a menu or to enter
numeric values. The Setup key allows the input of parameters required for the various functions of the unit.
When a menu is displayed, the previously stored selection is indicated by black rectangle :
1.3.3 Entering numbers :
Numbers are entered as follows:
The old numerical value will be displayed first..
Should the Clear key be pressed before any other key has been activated, the program cycle will be set back
without correcting the old value.
Pressing the Enter key validates the input value and the next menu is displayed.
All values to be input are selected in the same way as for a calculator. Plus and minus can be changed at any time
by pressing the +/- key.
The number of digits on the left hand side of the decimal point is max. 4 for mm and max. 2 for inch. The number of
digits after the decimal point depends on the resolution.
An input value can be started directly with the decimal point.
If an incorrect value is selected, press the Clear key and start again.
1.4 OPERATION
1/ Depending on the operating location, the independent base may be screwed onto the bottom of the unit, so that
the display is presented « face-on » to the operator.
2/ Connect the charger (Section 1.8.5). If the accumulators are completely flat, wait approx. 10 minutes before use.
3/ Connect one probe P2, P5, P10, P25 or P50 (Section. 1.8.8) or several probes if operating with one or more
D102/D108 units (Section 2.3).
4/ If there is need, connect one Opto-RS instrument to instrument input of D100S unit. To connect more than one
Opto-RS instrument, use D104 (max. 4).
5/ Switch on unit. On/Off
When operating autonomously (without charger) the symbol appearing at the top right of the screen
indicates the need to recharge the battery.
Duration of charge : min 15 hours.
