Sylvac D 100S - Accessories; Technical Specifications of D102 and D108 Units

66
2.4 TECHNICAL SPECIFICATIONS OF D102 AND D108 UNITS
D102/D108 units: Housing in Terblend plastic (= ASA+Polycarbonate :refer to characteristics
described in Section 1.12)
Clip-on legs: Polyurethane clip-on legs.
Front and rear panels : Aluminium and polycarbonate sheet front and rear panels.
Degree of IP protection : IP50 (according to IEC 529)
Weight of unit : D102 0.450 kg
D108 0.500 kg
Possible measuring error : max 1 µm (this error can be reduced by re-calibrating the D100S unit).
Operating temperature : between +5 and +40 °C
Storage temperature : between -20 and +60 °C
Power supply : via D100S display unit.
Packaging in synthetic material includes :
Order No
- 1 D102 unit (2 channels) 904.1102
- or 1 D108 unit (8 channels) 904.1108
- 1 command connecting cable 925.5601
- 1 probe connecting cable 925.5603
2.5 ACCESSORIES
Order No
- Command connection cable 2.5 m length 925.5602
- Probe connection cable 2.5 m length 925.5604
