1.6.14.4 Output format for 40 columns printer
For small printers with a paper width of approx. 80 to 120 mm.
Printing time per line may be entered, as small printers often have a limited input buffer.
As for the 80 col. Printer, a header can be added at the start of the printing process. This is carried out as
Described in the previous section. A new printout of the header can be activated by pressing the Print key
for two seconds.
a/printing example in normal measurement mode with tolerances activated and complete header :
SYLVAC SA
Piece ident. : COUVERCLE
Drawing nbr. : PM230.010.412
Work station : L 201
Date : 12/11/2003 Time : 14:45
CHANNEL MEAS.VALUE DEVIATION OUT OF TOL
1+ 2 13.421 5.071 5.051 E>
1+ 2 13.369 5.019 4.999 E>
1+ 2 13.405 5.055 5.035 E>
1+ 2 13.393 5.043 5.023 E>
b/ Printing example in scanning mode with activated tolerances (incomplete header) :
SYLVAC SA
Piece ident. : COUVERCLE
Date : 12/11/1998 Time : 14:49
CHANNEL MEAS.VALUE DEVIATION OUT OF TOL
PIECE 1 : WORK
1 8.385 0.035 0.015 E>
2 5.098 -0.002 E=
3 12.235 0.015 I =
4 7.010 0.010 E=
