10. V-BELT DRIVING SYSTEM/KICK STARTER
10-7
Inspection
The weight rollers are to press movable drive face
by means of centrifuge force.
Thus, if weight rollers are worn out or damaged,
the centrifuge force will be effect.
Check if rollers are worn or damaged. Replace it if
necessary.
Measure each roller’s outer diameter. Replace it if
exceed the service limit.
Service limit: 17.4 mm
Weight: 14.0 g
Check if drive face boss is worn or damaged and
replace it if necessary.
Measure the outer diameter of movable drive face,
and replace it if it exceed service limit.
Service limit: 23.94 mm
Measure the inner diameter of movable drive face,
and replace it if it exceed service limit.
Service limit: 24.06 mm
Reassembly/installation
Install weight rollers.
Caution
The weight roller two end surfaces are not
certainly same. In order to lengthen the roller life
and prevented exceptionally wears the
occurrence, Please end surface of the closure
surface counter clockwise assembles onto
movable drive face.
Install ramp plate.
Weight roller
Movable drive face
Drive face boss
Weight roller
Closure surface
Guide collar
Ramp plate
