Sym VS150 - Drive Face

10. V-BELT DRIVING SYSTEM/KICK STARTER
10-6
Drive Face
Removal
Remove left crankcase cover.
Hold generator flywheel with universal holder, and
then remove drive face nut.
Remove drive face.
Remove driving belt and movable drive face comp
from crankshaft.
Remove ramp plate.
Remove weight rollers from movable drive face.
Crankshaft
Drive face boss
Movable drive face
Ramp plate
Movable drive face
Universal holder
Weight roller
