11. FINAL DRIVING MECHANISM
Mechanism Diagram ··························· 11-1
Precautions in operation ···················· 11-2
Trouble Diagnosis······························· 11-2
Disassembly of Final Driving Mechanism
······························································ 11-3
Inspection of Final Driving Mechanism
······························································· 11-4
Bearing Replacement ·························· 11-5
Re-assembly of Final Driving Mechanism
······························································· 11-8
Mechanism Diagram
11-1
Bearing 6301C3
Dowel Pin 10x14
Dowel Pin 10x14
Final gear
Bearing 6203U
Bearing 6301C3
Bearing (TMB. 6301)
Bearing 6004U
Drive shaft
Counter shaft
Counter gear
Final shaft
11
Brearing CSB. 204
