12. ALTERNATOR/STARTING CLUTCH
12-4
A.C.G. Set Removal
Remove 2 mounted bolts from pulse generator
and 2 mounted bolts from wire clamper and then
remove it.
Remove 2 screws from right crankcase cover and
A.C.G. set.
Starting Clutch Removal
Use special tool for remove starting clutch gear
comp. as show in this figure.
Remove starting driven gear.
Remove mounting plate, starter reduction gear,
and the shaft.
Remove starting clutch gear comp.
2 bolts
Wire
2 bolts
2 bolts
Starting clutch gear
Starter reduction gear comp
