3. GENERAL INFORMATION
3-9
Specifications
MAKER VMEP MODEL HA15A6-4 (VS2)
Overall Length 1910 mm Front Telescopic Fork
Overall Width 740 mm
Suspension
System
Rear Twin Unit Swing
Overall Height 1125 mm Front 110 / 80 – 12 61L
Dimension
Wheel Base 1345 mm
Tire Specifications
Rear 130 / 70 – 12 64L
Front 58 kg Front Disk (ψ273 mm)
Rear 75 kg
Curb Weight
Total 133 kg
Brake System
Rear Drum (ψ130 mm)
Passengers/Weight Two /110 kg Max. Speed Above 100 km/h
Front 88 kg
Performance
Climb Ability Below 28°
Rear 155 kg
Primary
Reduction
Belt, 2.56 ~ 0.8
Weight
Total Weight
Total 243 kg
Secondary
Reduction
Gear
Type 4-Stroke Engine Clutch Centrifugal, dry type
Installation and
arrangement
Vertical, below center,
incline 80°
Reduction
Transmission C.V.T
Fuel Used Unlead gasoline Speedometer 0 ~ 140 km/h
Cycle/Cooling 4-stroke/water cooled Horn 93~112 dB/A
Bore 57.4 mm Muffler Expansion & Pulse Type
Stroke 57.8 mm
Exhaust Pipe Position and
Direction
Right side, and
Backward
Cylinder
Number/Arrange
ment
Single Cylinder Lubrication System
Forced circulation &
splashing
Displacement 149.6 cm
3
Solid Particulate
Compression Ratio 11.2 : 1 CO Below 5.5 g/ km
Max. HP 9 Kw / 8000 r.p.m
Exhaust
Concentrati
on
HC Below 1.2 g/ km
Max. Torque 12.16 Nm / 6500 r.p.m E.E.C. ─
Ignition system C.D.I. electronic ignition P.C.V. ─
Engine
Starting System
Kick and electrical
starter
Catalytic reaction control
system
Yes
