13. BODY COVER
13-3
Front cover
Remove
Loosen 8 screw frome the front cover.
Loosen 2 screw bottom of front handle cover.
Remove headlight coupler, and then remove front
cover.
Installation
Install in reverse order of removal procedures.
8 screws
2 screws
electric cord coupling
To this chapter contents
145
147
