10. V-BELT DRIVING SYSTEM/KICK STARTER
Clutch Outer/Driven Pulley
10-9
Disassembly
Remove drive belt and clutch outer/driven pulley.
Install clutch spring compressor onto the pulley
assembly, and operate the compressor to let the
wrench be installed more easily.
Caution
Do not press the compressor too much.
Hold the clutch spring compressor onto bench vise,
and then remove mounting nut with special service
tool.
Release the clutch spring compressor and remove
clutch weight and spring from driven pulley.
Remove seal collar from driven pulley.
Remove guide pin, guide pin roller, and movable
driven face, and then remove O-ring & oil seal
seat from movable driven face.
Inspection
Clutch outer
Measure the inner diameter of clutch outer.
Replace the clutch outer if exceed service limit.
Service limit: 125.5 mm
Clutch nut wrench
Clutch spring compressor
Collar
Movable driven face
Guide pin
Seal
Clutch outer
Inner
diameter
O-ring
Guide pin roller
Guide pin
