4. MAINTENANCE INFORMATION
Precautions in Operation······················ 4-1
Periodical Maintenance Schedule········ 4-2
Fuel Lines / Cable ·································· 4-3
Air Cleaner·············································· 4-4
Spark Plug·············································· 4-4
Valve Clearance ····································· 4-5
Carburetor Idle Speed Adjustment······· 4-6
Ignition System······································ 4-7
Cylinder Compression Pressure ·········· 4-7
Drive Belt················································ 4-8
Brake System (Front Disk Brake)········· 4-8
Brake Light Switch/Starting Inhibitor
Switch ················································· 4-10
Headlight Beam Distance ·················· 4-10
Clutch Disc Wear································ 4-10
Side Stand··········································· 4-11
Cushion··············································· 4-11
Nuts, Bolts Tightness ························ 4-11
Wheel/Tire··········································· 4-12
Steering Handle Top Bearing············ 4-12
Precautions in Operation
Specification
Fuel Tank Capacity 6000 c.c.
Capacity 1000 c.c.
Engine Oil
Change 900 c.c.
Capacity 150 c.c.
Transmission Gear oil
Change 120 c.c.
Clearance of throttle valve 2~6 mm
Type NGK CR8E
Spark plug
Gap
0.6~0.7 mm
“F” Mark in idling speed BTDC 13º / 1700 rpm
Full timing advanced BTDC 28º / 4000 rpm
Idling speed 1600±100 rpm
Cylinder compression pressure 12.0 ±0.2 kgf/cm²
Valve clearance: IN/EX 0.12 ± 0.02 mm
Front 110/80-12 61L
Tire dimension
Rear 130/70-12 64L
Single Front: 1.75 kg/cm² rear : 2.25 kg/cm²
Tire pressure (cold)
Two persons Front: 1.75 kg/cm² rear : 2.50 kg/cm²
Battery 12V8Ah (MF battery) type: TTZ10S
4
4-1
