11. FINAL DRIVING MECHANISM
11-8
Re-assembly of Final Driving
Mechanism
Apply with grease onto the oil seal lip of final
driving shaft.
Install countershaft, counter gear, final shaft and
final driving gear.
Install dowel pin and new gasket.
Install gear box cover and bolts, and tighten.
Torque value: 1.0~1.4kgf-m
Dowel pin
Gasket
7 bolts
Countershaft
Final drive gear
Final shaft
Drive shaft
