3. LUBRICA
TION SYSTEM
3-6
Oil Pump Inst
allation
Install the oil pump, and then tighten bolt
s.
T
orque value
：
0.8~1.2kgf-m
Make sure that oil pump shaft can be rot
ated
freely
.
Install oil pu
mp driving chain and sprocket, and
then install snap ring ont
o oil pump shaft.
Install st
arting gear and generator
.
(Refer to chapter 10)
