15. STEERING / FRONT WHEEL / FRONT CUSHION
15-8
Front Cushion
Remove
Remove front cover, front under spoiler and front
fender.
Remove front brake caliper.
Remove front wheel.
Remove front cushion upper mounting bolts, and
then remove front cushion.
Installation
Align the cover flange with upper level of the
cushion clamp, and then tighten bolts.
Torque value: 2.7kgf-m
Install the removed components in reverse order
of removal procedures.
4 bolts
