Sym VS150 User Manual

13. BODY COVER
13-15
Rear fender
Remove luggage box and seat.
Remove rear carrier.
Remove body cover.
Remove fuel tank.
Remove rear fender upper side bolts. (2 bolts)
Remove rear fender.
Installation
Install in reverse order of removal procedures.
Center fender
Remove air cleaner.
Remove center fender left side bolt. (1 bolt)
Remove center fender right side bolts, and then
remove center fender. (2 bolts)
Installation
Install in reverse order of removal procedures.
2 bolts
2 bolts
2 bolts
