14. BODY COVER

14-7

Front under spoiler

Remove

Remove front cover.

Loosen 4 screws of the inner box side.

Loosen 2 screws from front side of the front under

spoiler.

Remove the front under spoiler.

Installation

Install in reverse order of removal procedures.

4 screws

2 bolts
