13. BODY COVER
13-2
Maintenance
Body covers disassemble sequence:
y Be careful not to damage various covers in assembly or disassembly operation.
y Never injure hooks molded on the body covers.
y Align the buckles on the guards with slot on the covers.
y Make sure that each hook is properly installed during the assembly.
y Never compact forcefully or hammer the guard and the covers during assembly.
Front cover Seat & Luggage box
Center cover
Front under spoiler
Under cover
Inner box
Handle front cover
Handle rear cover
Floor panel
Rear fender
Body cover
Rear carrier
Right front fender B
Center cover
Left front fender B
Front fender
Center fender
Under cover
