12. ALTERNATOR/STARTING CLUTCH
12-3
Right Crankcase Cover Removal
Remove bolts and screws from the right crankcase
cover.
Remove cooling fan comp. (4 bolts 6×18) and then
remove it.
Flywheel Removal
Hold the flywheel by drive face with universal
holder, and remove its nut.
Special tool:
Universal Holder
Pull out flywheel with A.C.G. flywheel puller.
Special tool:
A.C.G. Flywheel puller
