3. LUBRICA
TION SYSTEM
3-5
Check clearance between inner and outer rotors.
Limit: 0.20 mm
Check clearance between rotor side face and
pump body
Limit: 0.12 mm
Oil Pump Re-assembly
Install inner and outer ro
tors into the pump body
Align the indent on driving shaft with that of inner
rotor
.
Install the driving
shaft
Install fixing pin
Install the oil pump cover and fixing pin properly
Pin
1 Screw
T
