3. GENERAL INFORMATION
3-12
Frame Torque Values
Item Q’ty Thread Dia. (mm) Torque Value(kgf-m) Remarks
Stopper nut for engine hanger
rubber
1 8 1.8~2.2
Engine hanger nut 2 12 4.0~5.0
Engine hanger bolt 1 12 4.0~5.0
Engine connection bolt 1 10 3.5~4.5
Front wheel axle nut 1 12 5.0~7.0
Rear wheel shaft nut 1 14 10.0~12.0
Rear fork 2 8 4.0~5.0
Rear cushion upper bolt 2 10 3.5~4.5
Rear cushion under bolt 2 8 2.4~3.0
Nut for steering post 1 10 4.0~5.0
Front cushion 4 8 2.4~3.0
Brake lever nut 2 6 0.8~1.2
Nut for the rear brake arm 1 6 0.5~0.6
Front brake hose bolt 4 10 3.0~4.0
Front brake caliper bolt 4 6 3.0~3.5
Front brake disk mounting bolt 7 8 4.0~4.5
Air-bleed valve 1 5 0.5~0.6
Speedometer cable locking screw 1 5 0.15~0.3
Exhaust muffler bolt 3 8 3.2~3.8
Exhaust muffler connection nut 2 7 1.0~1.2
