097-58001-01 Revision E – September 2006 TimeProvider TL1 Reference Guide 107
Chapter 2 TL1 Command Syntax and Description
Retrieve LED Status (RTRV-LED)
Retrieve LED Status (RTRV-LED)
This command retrieves the current state (color) of the various LED indicators that
are on the panels of the IMC and IOC modules.
This command has a default access level of USER.
Syntax
RTRV-LED:[<tid>]:[<aid>]:[<ctag>];
Command Output
The following shows the output format of the command, and Table 2-21 explains the
various fields in the command output:
Response Format
<cr><lf><lf>
sid date time<cr><lf>
M ctag COMPLD<cr><lf>
”<aid>:indicator,state”<cr><lf>
”<aid>:indicator,state”<cr><lf>
.
.
”<aid>:indicator,state”<cr><lf>
Parameter Value Description
<aid> (null) Retrieves the status of all LED indicators.
IMC Retrieves the status of the LED indicators on the IMC module.
IOC1 Retrieves the status of the LED indicators on the IOC1 module.
IOC2 Retrieves the status of the LED indicators on the IOC2 module.
Table 2-21. RTRV-LED Output Fields
Field Description
indicator The name of the LED indicator for which the state is retrieved. This corresponds to the
label on the panel of the unit.
state The current state of the LED indicator:
OFF – The indicator is currently not lit.
GREEN – The indicator is currently lit, and the color is green.
ORANGE – The indicator is currently lit, and the color is orange.
YELLOW – The indicator is currently lit, and the color is yellow.
RED – The indicator is currently lit, and the color is red.
FLASHING_GREEN – The indicator is currently alternating between OFF and
GREEN, at a 0.5 second rate.
