097-58001-01 Revision E – September 2006 TimeProvider TL1 Reference Guide 55
Chapter 2 TL1 Command Syntax and Description
Edit Sync (ED-SYNC)
Edit Sync (ED-SYNC)
This command changes factory settings and input and output port parameter
settings that can influence how the system’s signal synchronization operates.
This command has a default access level of ADMIN.
Syntax
ED-SYNC:[<tid>]:<aid>:[<ctag>]::<keyword>=<value>;
Parameter Value
Description
See
Table 2-6
for <keyword> and <value> descriptions
<aid> SYS The command’s effect is on system-level input settings.
GPS The command’s effect is on the GPS system input.
PRS The command’s effect is on the PRS system input.
INPp The command’s effect is on the input port specified by p:
p = “1” for the input marked INP 1 on the Input Connector
module
p = “2” for the input marked INP 2 on the Input Connector
module
OUTg The command’s effect is on the output group specified by g:
g = “A” for the group marked “A” on the main shelf
g = “B” for the group marked “B” on the main shelf
g = “C” for the group marked “C” on the main shelf
g = “D” for the group marked “D” on the main shelf
RTMg[-p] The command’s effect is on the Retimer group and port
specified by g[-p]:
g = “A” for the group marked “A” on the main shelf
g = “B” for the group marked “B” on the main shelf
g = “C” for the group marked “C” on the main shelf
g = “D” for the group marked “D” on the main shelf
p = “1” for Port 1 on the Retimer module
p = “2” for Port 2 on the Retimer module
E422g The command’s effect is on the EIA-422 output group
specified by g:
g = “A” for the group marked “A” on the main shelf
g = “B” for the group marked “B” on the main shelf
g = “C” for the group marked “C” on the main shelf
g = “D” for the group marked “D” on the main shelf
