097-58001-01 Revision E – September 2006 TimeProvider TL1 Reference Guide 111
Chapter 2 TL1 Command Syntax and Description
Retrieve Log (RTRV-LOG)
Input
RTRV-LOG:::IOC1:TP1000::EVT;
Event Response Example
TP-SSU 05-02-10 13:37:39
M TP1000 COMPLD
"IOC1,EQPT:BTBCKUP,SC,05-02-10,13-37-39,,,,:\"BESTIME BACKUP REFERENCES DISQUALIFIED\""
"IOC1,EQPT:CLKTYPE,TC,05-02-10,13-35-56,,,,:\"CLOCK TYPE HAS CHANGED\""
Alarm Response Format
<cr><lf><lf>
sid date time<cr><lf>
M ctag COMPLD<cr><lf>
”<aid>,aidtype:ntfcncde,condtype,srveff,ocrdat,ocrtim[:condscr]”<cr><lf>
”<aid>,aidtype:ntfcncde,condtype,srveff,ocrdat,ocrtim[:condscr]”<cr><lf>
.
.
”<aid>,aidtype:ntfcncde,condtype,srveff,ocrdat,ocrtim[:condscr]”<cr><lf>
;
ocrtim The time that the event occurred, in the format HH:MM:SS.
condscr The description of the alarm or event. It is a quoted text string, preceded with the “\”
escape character.
Note:
Table C-2
shows all of the possible TimeProvider event codes (event condition
strings), and
Table B-2
shows all of the possible TimeProvider alarm condition types.
Table 2-24. RTRV-LOG Alarm Output Fields
Field Description
aidtype Specifies if the event is associated with the internal operation of the system (EQPT),
or external to the system or facility (T1).
ntfcncde The notification code for the alarm or event. The notification code can be CR (critical
alarm), MJ (major alarm), MN (minor alarm), CL (clearing event), or NA
(non-alarmed event or report).
condtype The TL1 alarm or event code that is associated with the event or alarm.
Note:
Table C-2
shows all of the possible TimeProvider event codes (event condition
types), and
Table B-2
shows all of the possible TimeProvider alarm condition types.
srveff Whether the event is service affecting (SA) or non-service affecting (NSA).
ocrdat The date the event occurred, in the format YY-MM-DD.
ocrtim The time that the event occurred, in the format HH:MM:SS.
Table 2-23. RTRV-LOG Event Output Fields (Continued)
Field Description
