Chapter 2 TL1 Command Syntax and Description
Set Threshold (SET-TH)
136 TimeProvider TL1 Reference Guide 097-58001-01 Revision E – September 2006
Set Threshold (SET-TH)
This command sets the alarm threshold for performance monitored data, for
example MTIE and Fractional Frequency Offset.
This command has a default access level of ADMIN.
Syntax
SET-TH:[<tid>]:<aid>:[<ctag>]::<keyword>[=<value>];
Parameter Value
Description
See Table 2-35 for <keyword> and <value> descriptions
<aid> GPS The command’s effect is on the GPS system input.
PRS The command’s effect is on the PRS system input.
INP1 The command’s effect is on the INP1 system input.
INP2 The command’s effect is on the INP2 system input.
RTMg[-p] The command’s effect is on the specified Retimer module [and
Port]:
g = “A” for the group marked “A” on the main shelf
g = “B” for the group marked “B” on the main shelf
g = “C” for the group marked “C” on the main shelf
g = “D” for the group marked “D” on the main shelf
p = “1” for Port 1 on the Retimer module
p = “2” for Port 2 on the Retimer module
Table 2-35. SET-TH – Keywords and Values for all <aids>
<keyword> <value> Description Default
MASK GPS–R | PRS |
DS1 | OCN | PRC
| TYPEI | TYPEII
Set MTIE-x and FFOFF-60 thresholds to predefined
settings.
See
Table 2-36
MTIE-1 1 to 5000000 1-Second MTIE observation threshold defined in ns 10 000
MTIE-5 1 to 5000000 5-Second MTIE observation threshold defined in ns 50 000
MTIE-10 1 to 5000000 10-Second MTIE observation threshold defined in ns 100 000
MTIE-50 1 to 5000000 50-Second MTIE observation threshold defined in ns 500 000
MTIE-100 1 to 5000000
100-Second MTIE observation threshold defined in ns
1 000 00
MTIE-500 1 to 5000000
500-Second MTIE observation threshold defined in ns
5 000 000
