Chapter 2 TL1 Command Syntax and Description
Retrieve Craft Data (RTRV-CRAFT)
92 TimeProvider TL1 Reference Guide 097-58001-01 Revision E – September 2006
Retrieve Craft Data (RTRV-CRAFT)
This command retrieves information about the system state, clock mode of
operation, input provisioning, and output provisioning.
This command has a default access level of USER.
Syntax
RTRV-CRAFT:[<tid>]::[<ctag>];
Command Output
The following shows the output format of the command, and Table 2-16 describes
the various fields in the command output:
Response Format
<cr><lf><lf>
sid date time<cr><lf>
M ctag COMPLD<cr><lf>
"
SYS:<pwra>,<pwrb>,<expeqpt>,<extalm1>,<extalm2>,<ioc1eqpt>,<ioc2eqpt>,<sysqlevel>,
<lastdat>,<lasttim>,<syncmode>,<refmode>,<inpref>,<clrdelay>,<fltdelay>,<inacttime>,
<logecho>
"
<cr><lf>
"
IMC:<ioc1comm>,<ioc2comm>
"
<cr><lf>
"
COML:<baud>,<flow>,<echo>
"
<cr><lf>
"
COMR:<baud>,<flow>,<echo>
"
<cr><lf>
"
COMI:<ipaddr>,<ipgate>,<ipsubnet>,[<echo>]
"
<cr><lf>
[
"
IOC1:<iocstatus>,<ioccomm>,<imccomm>,<iocstate>,<iocmode>,<clkmode>,<clktype>"<cr><lf>]
[ IOC2:<iocstatus>,<ioccomm>,<imccomm>,<iocstate>,<iocmode>,<clkmode>,<clktype>
"
<cr><lf>]
"
GPS:<gpsstatus>,<instate>,<qlevel>,<priority>,<utc>,<mode>,<pos>,<elevmask>
"
<cr><lf>
"
PRS:<prsstatus>,<instate>,<qlevel>,<priority>,<frmtype>
"
<cr><lf>
"
INP1:<inpstatus>,<instate>,<qlevel>,<priority>,<frmtype>,<rqlevel>,<crcena>,
<ssmena>,<ssmbit>
"
<cr><lf>
”INP2:<inpstatus>,<inpstate>,<qlevel>,<priority>,<frmtype>,,
<rqlevel>,
<crcena>,
<ssmena>, <ssmbit>
"
<cr><lf>
"
OUTA:<outstatus>,<outstate>,<frmtype>,<freeflt>,<holdflt>
"
<cr><lf>
"
OUTB:<outstatus>,<outstate>,<frmtype>,<freeflt>,<holdflt>
"
<cr><lf>
"
OUTC:<outstatus>,<outstate>,<frmtype>,<freeflt>,<holdflt>
"
<cr><lf>
"
OUTD:<outstatus>,<outstate>,<frmtype>,<freeflt>,<holdflt>
"
<cr><lf>
"
RTMA-1:<rtmstatus>,<rtmstate>,<rtmlbo>,<freeflt>,<holdflt>,<rtmslip>”<cr><lf>
"
RTMA-2:<rtmstatus>,<rtmstate>,<rtmlbo>,<freeflt>,<holdflt>,<rtmslip>”<cr><lf>
"
RTMB-1:<rtmstatus>,<rtmstate>,<rtmlbo>,<freeflt>,<holdflt>,<rtmslip>”<cr><lf>
Notes:
The information displayed for the system input, output, and
expansion components is reported by the active IOC.
If neither IOC is active, the information for the input and output
components and some of the system components is determined by
the IOC1 module if it is installed, or the IOC2 module if the IOC1
module is not installed.
If the IMC module cannot read information from either IOC module,
the related information is not displayed in the command output.
If either an IOC1(2)EQPT or IOC1(2)COMM alarm is active, then no
IOC1(2) information is displayed.
