Chapter 2 TL1 Command Syntax and Description
Retrieve Log (RTRV-LOG)
110 TimeProvider TL1 Reference Guide 097-58001-01 Revision E – September 2006
Command Output
The following shows the event output format of the command and Table 2-23
explain the various fields in the output. The Alarm format follows this explanation of
events and Table 2-24 explains the fields in the alarm output:
Event Response Format
<cr><lf><lf>
sid date time<cr><lf>
alrmcde atag REPT EVT [AIDTYPE]<cr><lf>
"aid,aidtype:condtype,condeff,ocrdat,ocrtim,,,,:condscr"<cr lf>
"aid,aidtype:condtype,condeff,ocrdat,ocrtim,,,,:condscr"<cr lf>
.
.
"aid,aidtype:condtype,condeff,ocrdat,ocrtim,,,,:condscr"<cr lf>
;
Table 2-22. RTRV-LOG – Keywords for all <aids>
<keyword> Description Value
ALL (or null)
Retrieves both alarmed and non-alarmed events for the specified aid.
N/A
EVT Retrieves non-alarmed events for the specified aid. N/A
ALM Retrieves alarmed events for the specified aid. N/A
index A specified value to skip that number of events before displaying data. 1 to 500
count A specified value to retrieve that number of recent events or alarms. 1 to 500
start date Start date of the event history to display YY-MM-DD
stop date Stop date of the event history to display YY-MM-DD
Table 2-23. RTRV-LOG Event Output Fields
Field Description
aidtype Specifies if the event is associated with the internal operation of the system (EQPT),
or external to the system or facility (T1).
ntfcncde The notification code for the alarm or event. The notification code can be CR (critical
alarm), MJ (major alarm), MN (minor alarm), CL (clearing event), or NA
(non-alarmed event or report).
condtype The TL1 alarm or event code that is associated with the event or alarm.
Note: Table C-2 shows all of the possible TimeProvider event codes (event condition
types), and Table B-2 shows all of the possible TimeProvider alarm condition types.
condeff Defines the effect of the event on the system: CL indicates clearing of a standing
condition, SC indicates a standing condition is raised, and TC indicates a transition
of a condition.
ocrdat The date the event occurred, in the format YY-MM-DD.
