Chapter 2 TL1 Command Syntax and Description
Retrieve Built-In Self Test (RTRV-BIST)
82 TimeProvider TL1 Reference Guide 097-58001-01 Revision E – September 2006
Table 2-13. Retrieve Built-In Self Test Output Fields
Value Description
IMC condscr
RAM FAULT
NVRAM FAULT
GPS 1PPS FAULT (may occur during IOC startup)
NETWORK FAULT
SOFTWARE FAULT
UNKOWN FAULT [fault number]
NO FAULTS
IOC condscr
OUTPUT GROUP A CALIBRATION FAULT
OUTPUT GROUP B CALIBRATION FAULT
OUTPUT GROUP C CALIBRATION FAULT
OUTPUT GROUP D CALIBRATION FAULT
OUTPUT GROUP A FAULT
OUTPUT GROUP B FAULT
OUTPUT GROUP C FAULT
OUTPUT GROUP D FAULT
OUTPUT SYNTHESIZER UNLOCKED
VCXO CONTROL VOLTAGE FAULT
OCXO CURRENT LIMIT EXCEEDED
RUBIDIUM UNLOCKED
E1 PLL UNLOCKED
T1 PLL UNLOCKED
5V POWER SUPPLY FAULT
3.3V POWER SUPPLY FAULT
IMC POWER SUPPLY FAULT
15V POWER SUPPLY FAULT
1.8V POWER SUPPLY FAULT
–6V POWER SUPPLY FAULT
GPS POWER SUPPY FAULT
FPGA ACCESS FAULT
FPGA 40Hz FAULT
UNKNOWN FAULT [fault number]
NO FAULTS
