Symmetricom TimeProvider 1000 Reference Guide

Appendix B Alarms
152 TimeProvider TL1 Reference Guide 097-58001-01 Revision E – September 2006
INPFRQ The specified input port’s
calculated received
frequency is exceeding
the pull-in range of the
local oscillator. The
received signal’s
calculated frequency
alarmed condition
disqualifies the input as
a possible reference.
After INPFRQ is set, the
alarm clears when the
input frequency is within
the defined pull-in range
limits.
T1 NSA IMMEDNO MNMNNR
INPTRR
The specified CC input
port has a Tip/Ring
reversal on it’s
connection to the system.
T1 NSA IMMEDNO MNMNMN
EXDSC Input has had excessive
discontinuities. This is
indicated when there
are more than 3 signal
faults of the same type
within a 5-minute
window. The alarm
clears when the 5-
minute window contains
less than 3 alarms of the
same type.
T1 NSA IMMEDNO MNMNMN
MTIE Input has exceeded at
least one of the MTIE
alarm thresholds.
T1 NSA IMMEDNO MNMNMN
<aid> = E422A | E422B | E422C | E422D
E422FAULT
The EIA-422 Output
module is not functioning.
T1 NSA IMMED NO NA NA NA
<aid> = RTMA[-p] | RTMB[-p] | RTMC[-p]. | RTMD[-p]
S1LOS LOS on Side 1 T1 NSA IMMED NO MN MN MN
S2LOS LOS on Side 2 T1 NSA IMMED NO NA NA NA
EXSLIP Excessive Slip Rate T1 NSA IMMED NO NA NA NA
RTMFAULT The Retimer module is
not functioning properly
T1 NSA IMMED NO‘ NA NA NA
Table B-1. Alarms (Continued)
Alarm ID
or
CONDTYPE
Alarm Condition
Description
AID
Type
Service
Affecting
Error
Delay
Default
Error
Delay
Editable
Alarm Default
Level
SSU PRS SUB
