097-58001-01 Revision E – September 2006 TimeProvider TL1 Reference Guide 155
Appendix B Alarms
INP[p] Alarm Conditions
INPDISQ Input Disqualified as Possible Reference Input Qualified as Possible Reference
INPAIS AIS Fault AIS Fault Cleared
INPLOS LOS Fault LOS Fault Cleared
INPOOF OOF Fault OOF Fault Cleared
INPFRQ Frequency Threshold Exceeded Frequency Within Threshold
INPPHASE Phase Error Exceeded Threshold Phase Error Within Threshold
INPQL
Quality Level (SSM) Exceeded Threshold
Quality Level (SSM) Within Threshold
INPTRR Tip/Ring Connections Reversed Tip/Ring Connections Correct
EXDSC Excessive Discontinuity Fault Excessive Discontinuity Cleared
MTIE MTIE Threshold Exceeded MTIE Within Threshold
FFOFF FFOFF Threshold Exceeded FFOFF Within Threshold
E422g Alarm Conditions
E422EQPT EIA-422 Module is Unequipped EIA-422 Module is Equipped
E422FAULT EIA-422 Module has a Fault EIA-422 Module Fault Cleared
OUTg Alarm Conditions
OUTEQPT Output Module is Unequipped Output Module is Equipped
RTMg[-p] Alarm Conditions
RTMEQPT Retimer Module is Unequipped Retimer Module is Equipped
S1LOS Side 1 LOS Fault Side 1 LOS Fault Cleared
S2LOS Side 2 LOS Fault Side 2 LOS Fault Cleared
EXSLIP Slip Rate Threshold Exceeded Slip Rate Within Threshold
RTMFAULT Retimer Module has a Fault Retimer Module Fault Cleared
Table B-2. Alarm Code Condition Descriptions (Continued)
Alarm ID Set Alarm Condition Description Clear Alarm Condition Description
