Chapter 2 TL1 Command Syntax and Description
Edit Sync (ED-SYNC)
58 TimeProvider TL1 Reference Guide 097-58001-01 Revision E – September 2006
FRMTYPE 1.544M The PRS input frequency is provisioned as
1.544 MHz.
2M
2M The PRS input frequency is provisioned as 2 MHz
(2048 kHz).
5M The PRS input frequency is provisioned as 5 MHz.
6.312M The PRS input frequency is provisioned as
6.312 MHz.
10M The PRS input frequency is provisioned as 10 MHz.
Note: If the input frequency does not match the FRMTYPE setting,
an input loss-of-signal (INPLOS) condition results.
<aid> = INPp
QLEVEL Refer to the QLEVEL description under the <aid> =
GPS heading in this table.
PRIORITY Refer to the PRIORITY description under the <aid> =
GPS heading in this table.
FRMTYPE
Note: When the
TimeProvider is in
Subtending mode,
see “Set System
Mode
(SET-SYS-MODE
)” on page 134,
the frame signal
type is
automatically set
to Composite
Clock (CC or JCC)
by the system.
The Composite
Clock FRMTYPE
cannot otherwise
be selected by the
user.
2M Specified input frame signal type is 2M. 2M
ESF
CAS Specified input frame signal type is CAS.
CCS Specified input frame signal type is CCS.
D4
Specified input frame signal type is D4 (Super Frame).
ESF Specified input frame signal type is ESF (Extended
Super Frame).
1.544M
1
Specified input frame signal type is 1.544 MHz.
6.312M
1
Specified input frame signal type is 6.312 MHz.
CC Specified input frame signal type is Composite Clock.
JCC
1
Specified input frame signal type is Japanese
Composite Clock.
JCC4
1
Specified input frame signal type is Japanese
Composite Clock 400 Hz.
CRCENA ENABLE Enables the use of CRC4 checking on the input. DISABLE
DISABLE Disables the use of CRC4 checking on the input.
Note: If an input is provisioned to read SSMs (SSMENA=ENABLE),
CRC4 must be provisioned first.
Table 2-6. ED-SYNC – Keywords and Values (Continued)
<keyword> <value> Description Default
