Symmetricom TimeProvider 1000 Reference Guide

Chapter 2 TL1 Command Syntax and Description
Retrieve Condition (RTRV-COND)
88 TimeProvider TL1 Reference Guide 097-58001-01 Revision E – September 2006
Command Output
The following shows the output format of the command when the “ALL” aid is used,
and Table 2-15 explains the various fields in the command output:
Response Format
<cr><lf><lf>
sid date time<cr><lf>
M ctag COMPLD<cr><lf>
"SYS:<pwra>,<pwrb>,<expneqpt>,<extfault>,<ioc1eqpt>,
<ioc2eqpt>,<sysqlevel> <lastdat>,<lasttim>
"<cr><lf>
"IMC:<ioc1comm>,<ioc2comm>"<cr><lf>
[
"IOC1:<iocstatus>,<ioccomm>,<imccomm>"<cr><lf>]
[
"IOC2:<iocstatus>,<ioccomm>,<imccomm>"<cr><lf>]
"GPS:<gpsstatus>"<cr><lf>
"PRS:<prsstatus>"<cr><lf>
"INP1:<inpstatus>"<cr><lf>
"INP2:<inpstatus>"<cr><lf>
"OUTA:<outstatus>"<cr><lf>
"OUTB:<outstatus>"<cr><lf>
"OUTC:<outstatus>"<cr><lf>
"OUTD:<outstatus>"<cr><lf>
"RTMA:<rtm1status>,<rtm2status>"<cr><lf>
"RTMB:<rtm1status>,<rtm2status>"<cr><lf>
"RTMC:<rtm1status>,<rtm2status>"<cr><lf>
"RTMD:<rtm1status>,<rtm2status>"<cr><lf>
"E422A:<outstatus>"<cr><lf>
"E422B:<outstatus>"<cr><lf>
"E422C:<outstatus>"<cr><lf>
"E422D:<outstatus>"<cr><lf>
;
<aid>
(cont’d)
RTMg Retrieves status of the Retimer group specified by g.
 g = “A” for the group marked “A” on the main shelf
 g = “B” for the group marked “B” on the main shelf
 g = “C” for the group marked “C” on the main shelf
 g = “D” for the group marked “D” on the main shelf
Note: This information is reported by the active IOC.
E422g Retrieves status of the EIA-422 output group specified by g.
 g = “A” for the group marked “A” on the main shelf
 g = “B” for the group marked “B” on the main shelf
 g = “C” for the group marked “C” on the main shelf
 g = “D” for the group marked “D” on the main shelf
Note: This information is reported by the active IOC.
Parameter Value Description
