System Components
Revision G Issued May 2022
Page 4
MAIN SYSTEM COMPONENTS
A
B
C
A. Computer (Controller)
B. Instrument
C. Power Supply Enclosure
D. Forced Convection Oven Enclosure
E1. Liquid Nitrogen Controller & LN
2
Tank
OR
E2. Air Cooling System
D
E1
E2
