RSA-G2 Getting Started Guide Page 30
Instrument Specifications
The table found below contains the technical specifications for the RSA-G2.
Table 4: RSA-G2 Technical Specifications
Item/Area Specifications
Test station Depth 56 cm (22 in.)
Width 46 cm (18 in.)
Height 104 cm (39.37 in.)
Power supply enclosure Depth 48 cm (19 in.)
Width 32 cm (12.5 in.)
Height 34 cm (13.5 in.)
Oven supply enclosure Depth 48 cm (19 in.)
Width 32 cm (12.5 in.)
Height 11 cm (4.5 in.)
Weight:
Test station
Power supply enclosure
Oven supply enclosure
104.5 kg (< 230 lbs)
12.7 kg (28 lbs)
6.8 kg (15 lbs)
Power:
Test station
Power supply enclosure
Oven supply enclosure
From power supply:
90 – 264 VAC, 16 amps max
180 – 264 VAC, 47 – 63 Hz, 13 amp max
Operating environmental conditions Temperature: 15–30°C
Relative humidity: 5–80% (non-condensing)
Installation Category II
Pollution degree 2
Maximum altitude: 2000 m (6560 ft)
Minimum clearances of six inches from top and all sides,
and eight inches from temperature control options.
The degree of protection for this instrument according to
EN 60529 is IP20.
TEMPERATURE SYSTEMS
Forced Convection Oven (FCO) –150 to 500°C (lower limit dependent on cooling device)
FCO Camera Viewer Optional
Precision +
0.05°C
Stability +
0.1°C
