RSA-G2 Getting Started Guide Page 33
Moving the RSA-G2 Using a Cart (Highly Recommended)
1 Obtain a cart that is wide enough to accommodate the instrument and able to support at least 250 lbs
(114 kg). If possible, raise the cart until the top surface is level with your lab bench.
2 Position one person on the lighter side of the instrument (to the left as you face the instrument), and two
people on the heavy side of the instrument (to the right as you face the instrument). Carefully slide the
RSA-G2 onto the cart.
3 Wheel the cart to the desired location, slide the instrument onto the bench top, and remove the lifting
handles.
Moving the RSA-G2 Without a Cart
When moving the RSA-G2 without a cart, you must have three people to perform the following procedure:
1 The handling points on the instrument are shown. Grasp the instrument at those points.
Figure 16 Instrument handling points (ARES-G2 shown).
2 Position one person on the lighter side of the instrument (to the left as you face the instrument), and two
people on the heavy side of the instrument (to the right as you face the instrument).
3 Grasp the instrument as follows.
Light side: One person holds both lifting handles.
Heavy side: Each person holds one handle and puts free hand on the top section to support it.
4 Using proper lifting technique, lift and carry the instrument to the desired location.
5 When you have positioned the instrument at the desired location, remove the lifting handles and replace
the corner plugs.
Support top section
Heavy side
Grasp all four handles (last
handle not visible
