RSA-G2 Getting Started Guide Page 41
Connecting Cables and Lines
To connect the cables and gas lines, you will need access to the RSA-G2 rear panel. All directional
descriptions are written on the assumption that you are facing the back of the instrument.
CAUTION: Connect all cables before connecting the power cords to outlets. Tighten the
thumbscrews on all computer cables. Whenever plugging or unplugging power cords, handle them
by the plugs, not by the cords.
MISE EN GARDE: Raccordez tous les câbles avant de connecter les cordons d'alimentation aux
prises. Serrez les vis à serrage à main sur tous les câbles d'ordinateur. Chaque fois que vous bran-
chez ou débranchez les cordons d'alimentation, tenez-les par les fiches et non par les cordons.
Connecting the Modular Power Supplies
Stackable power supplies are used with the RSA-G2 to house various printed circuit boards and electrical
components. They provide power and communication with the instrument. Follow these instructions to
connect the power supplies to the instrument and accessories.
WARNING: Protect power and communications cable paths. Do not create tripping hazards by
laying the cables across access ways.
AVERTISSEMENT: Protégez les chemins de câble électriques et de câbles de télécommunica-
tion. Ne créez pas de risques de déclenchement en posant des câbles sur les voies d'accès.
