Accessories
Revision G Issued May 2022
LIQUID NITROGEN CONTROLLER MEASUREMENTS
LIQUID NITROGEN CONTROLLER REQUIREMENTS
Should be placed on the same side as the FCO
Customer must provide: 160 L (or larger) Liquid Nitrogen tank with a pressure of
14–22 psig (95–150 kPa gauge)
LN2 pressure above 30 psig (207 kPa gauge) may cause damage to the Liquid
Nitrogen Controller.
Keep the supply line short and provide adequate insulation to minimize
gaseous nitrogen build-up in the supply line. Failure to do so may cause the
Liquid Nitrogen Controller to malfunction frequently. Use the 3 ft. hose
provided by TA Instruments for this reason.
Circulator Power Cooling Gas LN
2
Fluid Light Hardware Software Temp Lab Customer
Weight when EMPTY: 14 kg (30 lbs)
Weight when FULL: 15 kg (33.5 lbs)
