TA Instruments RSA-G2 - Accessories; ACS and Chiller Panel

Page 9
Page 9
Accessories
Revision G Issued May 2022
Page 9
ACS-2 MEASUREMENTS
ACS-3 MEASUREMENTS
Height: 88.5 cm (35 in)
Depth: 56 cm (22 in)
Weight: 96 kg (211 lbs) WITHOUT Chiller Panel
Width: 67 cm (26.5 in)
Weight: 112 kg (247 lbs) WITH Chiller Panel
Height: 112 cm (44 in)
Width: 67 cm (26.5 in)
Depth: 56 cm (22 in)
Weight: 121 kg (267 lbs) WITHOUT Chiller Panel
Weight: 137 kg (302 lbs) WITH Chiller Panel
