Takeuchi TB153FR User Manual

105
TRANSPORT
Cautions on TransportingSecuring the Machine
TRANSPORT
After loading the machine in the designated
position, secure it as described below.
Transporting Posture
1. Lower the blade.
2. Fully extend the bucket and arm cylinders,
then lower the boom.
3. Stop the engine and remove the starter
key.
4. Raise the safety lock lever to engage the
lock.
5. Set stoppers in front and behind the
crawlers.
6. Put a chain or wire rope over the lower
frame and fasten it securely to prevent
sideways slippage.
7. Secure the bucket with a chain or wire
rope.
IMPORTANT: Place a wooden block
under the bucket so that it is not damaged
by hitting the floor.
WARNING
¡¡
¡¡
¡ Know and follow the safety rules,
vehicle code and traffic laws when
transporting the machine.
¡¡
¡¡
¡ Consider the length, width, height and
weight of the truck with the machine
loaded on it when determining the best
route.

Takeuchi TB153FR Specifications

General

Engine Make	Yanmar
Engine Model	4TNV88
Tail Swing Type	Zero Tail Swing
Maximum Reach	5, 570 mm
Max Reach Ground Level	5, 570 mm
Transport Width	2, 000 mm
Transport Height	2, 600 mm
