Takeuchi TB153FR User Manual

70
OPERATION
Starting and Stopping the Engine < TB153FR >
Starting in Cold Weather
1. Pull the throttle lever to the middle position.
2. Turn the key to the PREHEAT position and
hold it there while the glow lamp is lit (about
15 seconds).
3. After the glow lamp turns off, then turn it
to the START position and start the engine.
4. Once the engine starts, release the key.
The key automatically returns to the ON
position.
5. Check that the warning lamps are off.
6. Return the throttle lever and warm up the
engine.
Refer to page 71 “Warming Up the
Engine”.
Starting the Engine
WARNING
¡¡
¡¡
¡Clear the area of all persons.
¡¡
¡¡
¡Sound horn to alert everyone around
the machine.
IMPORTANT: Do not run the starter motor
for more than 15 consecutive seconds. If
the engine fails to start, wait for 30
seconds to protect the battery, and then
try again to start the engine.
Normal Starting
1. Pull the throttle lever to the middle position.
2. Turn the key to the START position and
start the engine.
3. Once the engine starts, release the key.
The key automatically returns to the ON
position.
4. Check that the warning lamps are off.
5. Return the throttle lever and warm up the
engine.
Refer to page 71 “Warming Up the
Engine”.
D5D014E
D5D014E
PREHEAT
START
OFF
ON
E4D005
PREHEAT
OFF
ON
START
E4D060

Takeuchi TB153FR Specifications

General

Engine Make	Yanmar
Engine Model	4TNV88
Tail Swing Type	Zero Tail Swing
Maximum Reach	5, 570 mm
Max Reach Ground Level	5, 570 mm
Transport Width	2, 000 mm
Transport Height	2, 600 mm
