Takeuchi TB153FR User Manual

176
SPECIFICATIONS
Main Specifications
TB153FR
ENGINE
Manufacturer and model Yanmar 4TNV88-PTBZ1
Rated output kW / min
–1
(hp / rpm) 28.9 / 2400 (38.7 / 2400)
Displacement mI (cu.in.) 2189 (133.6)
Starter V – kW 12 – 2.3
Alternator V – kW 12 – 0.48
Battery V – Ah 12 – 72
Sound-power level L
WA
96
Sound-pressure level L
pA
76
MASS
Machine mass kg (lb.)
(not including operator)
Rubber crawlers
5505 (12135) 5615 (12375)
{5540 (12215)} {5645 (12445)}
PERFORMANCE
Bucket capacity m
3
(cu.ft.)
(standard bucket)
Heaped 0.141 (4.98)
Struck 0.102 (3.60)
Slew speed min
–1
(rpm) 9.8 (9.8)
Ground pressure
kPa (psi)
Rubber crawlers
31.6 (4.58) 32.2 (4.67)
{31.8 (4.61)} {32.4 (4.69)}
Travel speed km/h (mph)
1st 2.8 (1.74)
2nd 5.0 (3.11)
1st 2.5 (1.55)
2nd 4.7 (2.92)
Gradeability (degrees) 30
TYPE CANOPY CAB
Noise level dB(A)
Rubber
crawlers
Steel
crawlers
Steel crawlers
5575 (12285) 5680 (12525)
{5605 (12355)} {5715 (12600)}
Steel crawlers
32.0 (4.64) 32.6 (4.72)
{32.2 (4.67)} {32.8 (4.75)}
{ } : Long Arm

Takeuchi TB153FR Specifications

General

Engine Make	Yanmar
Engine Model	4TNV88
Tail Swing Type	Zero Tail Swing
Maximum Reach	5, 570 mm
Max Reach Ground Level	5, 570 mm
Transport Width	2, 000 mm
Transport Height	2, 600 mm
