Takeuchi TB153FR User Manual

205
OPTIONS
Pre Cleaner < TB180FR >
Inspecting and Cleaning the Pre
Cleaner
WARNING
¡¡
¡¡
¡ Stop the engine and allow the machine
to cool down before performing
maintenance.
• The engine, muffler, radiator and
many other parts of the machine are
hot directly after the engine is
stopped. Touching these parts will
cause burns.
¡¡
¡¡
¡ Wear required appropriate equipment
such as safety glasses and filter mask
when using compressed air, as metal
fragments or other objects can fly and
cause serious personal injury.
IMPORTANT: When operating the
machine in very dusty places, inspection
and maintenance should be performed
every day.
IMPORTANT: If the air cleaner warning
lamp flashes and an alarm is sounded
during operation, stop the engine
immediately and inspect and/or clean.
Inspection
1. Inspect for any dirt or dust accumulated
in the dust cup (3).
2. If dust has accumulated, clean the dust
cup (3).
Cleaning
1. Loosen the wing nut (1) and remove the
cover (2).
2. Remove the dust cup (3).
3. Clean the inside of the dust cup (3).
4. Install the dust cup (3) and cover (2) and
tighten the wing nut (1).

Takeuchi TB153FR Specifications

General

Engine Make	Yanmar
Engine Model	4TNV88
Tail Swing Type	Zero Tail Swing
Maximum Reach	5, 570 mm
Max Reach Ground Level	5, 570 mm
Transport Width	2, 000 mm
Transport Height	2, 600 mm
